Zumtobel Lighting GmbH

Zumtobel Arcos 2 Xpert Led Bluetooth®

ARCOS 2 XPERT LED BLUETOOTH®

ARCOS 2 XPERT LED BLUETOOTH®

-Countersunk pivot  -Spotlight rotates through 365° and pivots through 90° -Mains voltage: 220–240 V / 50/60 Hz -Must be installed in ceiling for use as point outlet

Zumtobel Arcos 2 Xpert Led Bluetooth®
Zumtobel Arcos 2 Xpert Led Bluetooth®
Zumtobel Arcos 2 Xpert Led Bluetooth®

- Luminiare can only be wall-mounted when used with Zumtobel 3-phase universal adapter and wall-mounting bracket  - LED spotlight "xpert stableWhite" with outstanding colour rendering (LED module: XICATO ARTIST)   - Optimized for efficient and high quality accent lighting in museums, exhibition spaces and art gallerie  - Housing made of die-cast aluminium - Colour: white micro-textured paint

INFORMATION

FEATURES

- Front ring provides excellent glare control
- More than one accessory at once can be fitted without tools on the front ring
- Axes of movement can be fixed separately using Allen key
- Dimming of illuminance (0.1–100 %) using rotary potentiometer, fine adjustment via Bluetooth®
- Flicker-free light
- Specular reflector of aluminised PC, highly specular, iridescence-free
- Service life: 50000 h at 80 % luminous flux
- Colour temperature: 3000 K (LED930: warm white)
- Colour rendering: Ra 9 95
- Luminaire luminous flux up to 800 lm

3-PHASE LED SPOTLIGHT, FLOOD (WITH UNIVERSAL ADAPTER)

Zumtobel Arcos 2 Xpert Led Bluetooth®
Zumtobel Arcos 2 Xpert Led Bluetooth®

3-PHASE LED SPOTLIGHT, SPOT (WITH UNIVERSAL ADAPTER)

Zumtobel Arcos 2 Xpert Led Bluetooth®
Zumtobel Arcos 2 Xpert Led Bluetooth®

ARCOS 2 LED XPERT

Compact, dimmable LED spotlight with excellent colour rendering (Ra 98) and narrow colour tolerances (1 x 2-step MacAdam); optionally available with super-spot, spot, flood or wideflood beam angles and with an oval or a square light distribution. New: ARCOS LED xpert blu Ø 100 mm. Fitted with LED modules of up to 22 W.

ACCESSORY

Zumtobel Arcos 2 Xpert Led Bluetooth®
