Loupi Mast 2c Spot Light
MAST 2C SPOT LIGHT
MAST 2C SPOT LIGHT
This mast with two miniature spots is designed for precision lighting.
Its excellent performance and small, sleek design make it very easy to fit in shop windows, display units, and other small spaces. It has multiple configurations: Surface finish, pole height, distance between each spots, colour temperature and beam angle
INFORMATION
OPTICAL
- Luminous flux according to Bining : 150 lumens by spot.
- Colour temperature : 2400 K to 5000 K.
- Service Range : 70 % of nominal flux after 25 000 hours.
- Colour Rendering Index : CRI 80 or CRI 90.
- PMMA acrylic lens, efficiency ~90 %.
- Available degrees : 16°, 24°, 40° & Elliptic.
MECHANICAL
- Mast : Diameter 6mm, Made-to-measure heights on request (Max : 600mm).
- Orientation by patented magnetic ball joint.
- Fixing integrated with bracket, or fixing cover attached to it.
- Operating temperature : -5° +40°.
- ROHS components.
- Interior use only.
ELECTRICAL
- Constant current supply : 500 mA.
- Supply connection : Polarised output connectors.
- Power consumption to 3W max, excluding supply.
- Electrical Classification : Class III SELV device.
DIMENSIONS
- Height: Max 600mm
- Base: 34mm
SPECIFITIES
- Electrolytic treatment available.
- 3 years guarantee.
COLORS
NORMS AND STANDARDS
