Panzeri Zero Square

ZERO SQUARE

Panzeri Zero Square

ZERO SQUARE

Designed By Enzo Panzeri 2019

Suspension lamp in extruded curved aluminium with opal polycarbonate screen. Emission on the internal side provided by LED modules with technology DALI / PUSH DIM integrated into the canopy.

Polyacrilic paint white, black, titanium, bronze and mat brass finishes are available. Custom colors are available on request. Canopies for single and multiple configurations with Zero Ellipse and Zero Round are available, to be ordered separately. Ideal for offices, halls, living, and public spaces.

Panzeri Zero Square

INFORMATION

LIGHT SOURCE

LED

OPTICS

Diffused

ELECTRICAL CONFIGURATION

NA

LIGHT SOURCE LIFETIME

L70 (B50) 60.000 h

COLOR TEMPERATURE

- 2700K Ra>90

POWER SUPPLY

24V DC

DRIVER

Remote Not Included

COLOR TOLLERANCE

DCM 3

PROTECTION DEGREE

IP20

COLORS

- White
- Black
- Bronze
- Matt Brass
- Titanium

Panzeri Zero Square
White
Panzeri Zero Square
Black
Panzeri Zero Square
Bronze
Panzeri Zero Square
Matt Brass
Panzeri Zero Square
Titanium

SUSPENSION WITHOUT CANOPY

DETAIL

- Single or multiple suspension lighting fixture for interiors, with direct and indirect light emission.Bended extruded aluminium structure in white, black, bronze, matt brass or titanium polyacrylic paint.
- Extruded polycarbonate diffuser with opaline finish.
- Suspension kit with griplocks and 5m (196,9") long steel cables.5m (196,9") long power cable in transparent PVC.Provided without power canopy.

Panzeri Zero Square

LENGTH 50 CM ODEM03201.050.0510

- System Power Consumption: 25W
- Efficacy: 81.56 l m/W
- Nominal Luminous: FLUX2835lm
- Lumen Output: 2039lm
- Efficiency: 71.922%
- Weight: 0,9500 Kg
-Packing Dimensions (cm): 8 x 56 x 56

Panzeri Zero Square
Polar Pattern
Panzeri Zero Square
Technical Drawing
Panzeri Zero Square

LENGTH 75 CM ODEM03201.050.0510

- System Power Consumption : 34W
- Efficacy: 89.97lm/W
- Nominal Luminous: FLUX4252lm
- Lumen Output: 3059lm
- Efficiency: 71.943%
- Weight: 1,2100Kg
- Packing Dimensions (cm): 6 x 80 x 80

Panzeri Zero Square
Polar Pattern
Panzeri Zero Square
Technical Drawing
