Aactiu Transit
TRANSIT
TRANSIT
Maximum optimization of energy use. Minimal environmental impact.
Last generation technological systems. Zero discharge of wastewater. No VOC coatings.
Processes free of heavy metals, phosphates, OC and COD.
FEATURES
TOP QUALITY
Modern Architecture: A bench seating system with massive potential for public areas, top quality finishes inspired in the most modern architecture.
POLYURETHANE
Soft Touch: Padded polyurethane benches provide a soft touch apart from its comfort. Original and contemporary, it is the fruit of innovation and the application of the latest technology materials
ORGANIC
Designs: Soft and organic designs to create the plywood bench seating. Simple but ergonomic, delicate but plain.
INFORMATION
MATERIAL
Maximum use of materials to eliminate and minimize scraps. Use of recyclable and recycled materials in those components that do not affect the functionality and durability.
TRANSPORT
Detachable systems. Volumes that facilitate the optimization of space. Maximum reduction of energy consumption by transport
DISPOSABLE
Waste reduction. Supplier-manufacturer packaging reuse system. Components are easy to be separated. Inks in packaging are water-based, without solvents.
USE
Quality and warranty. Long lasting. Replacements available.
CERTIFICATE
The different programmes get points in different environmental categories to get the LEED certificate (sustainability, material and resources, water, energy and atmosphere, inner environment quality, innovation and design).
MODELS
POLYRETHANE (PU)
1. PU seat and backrest 20 mm thickness in back and 25 mm thickness in seat; Moulded over Steel plate 3 mm thickness
2. Available in different finishes
3. Moulded aluminium trims available in silver or white finish
4. Optional moulded aluminium Arms available in silver, white or polished aluminium
5. Lower Beam in extruded aluminium
6. Optional 13 mm compact laminate table. Available in black or white 500 x 300 mm
7. Moulded aluminium feet, silver epoxy finish, 90 micron. Available in silver, white or polished finish. Ready to be fixed to the floor
8.Black polypropylene (P.P) caps to avoid sliding when sitting in the bench
DIMENSIONS
- Height: from 1726 to 3474 mm
- Width: 800 or 900 mm
- Seat height: from 440 mm
BACK REST AND SEAT FINISH
- Red - Blue - Black - Grey
STEEL
1. 3 mm steel seats and backs available in different finishes
2. Seat and backrest joined by an extruded aluminium central beam. Silver and white finishes
3. Moulded aluminium trims available in silver or white finish
4. Optional moulded aluminium Arms available in silver, white or polished aluminium
5. Lower Beam in extruded aluminium
6. Moulded aluminium feet, silver epoxy finish, 90 micron. Available in silver, white or polished finish. Ready to be fixed to the floor
Black polypropylene (P.P) caps to avoid sliding when sitting in the bench
7. Optional 13 mm compact laminate table. Available in black or white 500 x 300 mm
DIMENSIONS
- Height: from 1726 to 3474 mm
- Width: 800 or 900 mm
- Seat height: from 440 mm
BACK AND SEAT
- Silver - Black - Red - White
PLYWOOD
1. 13,53 mm Plywood seats and backs available in different finishes: natural beech, natural oak or wengue
2. Seat and backrest joined by an extruded aluminium central beam. Silver and white finishes
3. Moulded aluminium trims available in silver or white finish
4. Optional moulded aluminium Arms available in silver, white or polished aluminium
5. Lower Beam in extruded aluminium
6. Moulded aluminium feet, silver epoxy finish, 90 micron. Available in silver, white or polished finish. Ready to be fixed to the floor
Black polypropylene (P.P) caps to avoid sliding when sitting in the bench
7. Optional 13 mm compact laminate table. Available in black or white 500 x 300 mm
DIMENSIONS
- Height: from 1726 to 3474 mm
- Width: 800 or 900 mm
- Seat height: from 440 mm
BACK AND SEAT
- Natural Beech - Natural oak - Wengue Oak
