LIGHT ON Wall Light
LIGHT ON WALL LIGHT
In connection with the 100 year anniversary of Ifö in 1987, Knud Holscher designed the series Light On in clean, simple lines – it is still just as beautiful.
Light On are available both as classic light fittings and as downlights. They are nice on their own and are fantastic in groups. Light On are equally suitable in bathrooms and laundry rooms and kitchens as well as outside.
INFORMATION
DIMENSIONS
- Height: 167cm
- Diameter: 99cm
SPARE PARTS
- Shade: Part no 1-6117
- Gasket: Part no 3737-1
TECHNICAL INFORMATION
- Silicone gasket between glass and base.
- Four Ø 5mm holes for installation.
- CC measurement 56 mm
- Alternatively
- Mounting plate for ceiling installation box with CC measurement 70 mm.
- One bottom inlet for two mains supply cable.
- Two mantle screws for connection of max 2 x 2,5 mm
- Bridging is possible.
- Bottom inlet, two knock out openings.
MAINTENANCE
Switch off the power to the fixture. Remove the shade and clean it. Do not use cleaning agents containing solvents. Change the light source if necessary. Check the gasket and change it if necessary. Replace the shade.
SPECIFICATIONS
- Base material: Porcelain
- Lampholder: E27
- Light source Max: 60W (not incl.)
- Voltage: 230V
- Installation: Ceiling/wall
- Base colour: White NCS S 1502-G50Y
- Safety class: II
- Protection class: IP44
- Energy class - Ta -30 - +25
- Glass: Shiny opal
- Thread: 74 mm
- Weight: 1,3 kg
PPRODUCT NO
4050-500-10
SERIAL NO.
4211999
EAN NO
7312904050108
INSTALLATION
Insert the mains supply cable through the bottom inlet. Fix the light fitting to a wall with suitable screws. Connect the leads to the mantle screws. Fasten the lamp holder. Insert a light source and then fasten the shade by turning it clockwise. Make sure the gasket between the glass and base is in place.
