Luminis Pendant Lights - Lumistik
PENDANT LIGHTS - LUMISTIK CL314
PENDANT LIGHTS - LUMISTIK CL314
FEATURES
ENHANCE YOUR SPACE
Complete family of bollards, columns, pendants and wall luminaires available in various heights and diameters to compliment any space.
INNOVATIVE LIGHT
An innovative solution to accent light in various directions and to emphasize multiple elements creating unique spaces.
APPLICATIONS
Ideally suited for unique site lighting applications where public space enhancement is the goal.
INFORMATION
MATERIAL
Metal
SOURCE
LED
LOCATION
Interior
PRODUCT FAMILY
LUMISTIK
USE
Interior and exterior lighting
SIZES
3", 6" and 8" diameters
LIFE
50,000hrs L85B50 (based on IESNA TM-21 Test Method and LM-80 data).
LED
3000K/3500K/4000K CCT with 80 CRI. Optional RGBW.
FINISH
Five-stage preparation process including preheating of cast aluminum parts for air extraction, and an environmentally friendly alloy sealant. Polyester powder coating is applied through an electrostatic process and oven cured for long term finish.
CHARACTERISTICS
Extruded aluminum housing and cast aluminum mounting box, Stainless steel hardware, UV stabilized acrylic lens, Optional uplight and/or downlight module available, Optional RGBW
APPLICATIONS
Schools, Public spaces, Office buildings, Shopping centers and hospitals
APPLICATION AND USE IN CONSTRUCTION
Exterior / Outdoor, Interior
MATERIALS
LumiSTIK wall is made of seamless extruded corrosion resistant 356 aluminum alloy with a copper (CU) content of less than 0.1%. LED is contained in a white translucent high impact UV stabilized acrylic sealed lens. The assembly is designed to provide a uniform illumination.
LIFE
50,000hrs L85B50 (based on IESNA TM-21 Test Method and LM-80 data).
MOUNTING
Weight: CL314: 5 lbs (2.3 kg), CL324: 5.9 lbs (2.7 kg)
The mounting plate is designed to fit on a 2X4” (51x102mm) rectangular electrical box using 3.156” (80mm) C/C mounting holes. Optional trimming plate for octagonal jbox (option MT4).
CERTIFICATION
Certified and Approved as per CSA C22.2 No.: 250.0 standard and ANSI/UL 1598 standard, for wet location. Rated IP66.
ELECTRICAL
Standard driver is 0-10V dimming-ready (dims to 10%) with: 120-277 multi-volt compatibility (50-60Hz), operating temperatures of -30ºC/-22ºF to 60ºC/140ºF, output over voltage protection, output over current protection, output short circuit protection with auto-recovery. Driver for RGBW operating temperature range -20ºC to +50ºC/-4ºF to +122ºF
