Iguzzini UFO - Street Light

UFO - STREET LIGHT

Iguzzini UFO - Street Light

UFO - STREET LIGHT

UFO comfort pole mounted 423x423mm

Street lighting system for use with LEDs.

Iguzzini UFO - Street Light

INFORMATION

PRODUCT TYPE

Street Light

VISUAL

High visual comfort.

Iguzzini UFO - Street Light

LIGHTING SYSTEM

Street lighting system for use with LEDs.

LIGHT DISTRIBUTION

Available with 5 different light distributions.

THICKNESS

5 mm

DIAMETERS

60/76/89/102/ 114/120 mm

LED UNIT

Replaceable

COLOURS AVAILABLE

B5 Grey/white

INSTALLATION

Installation with Arms on Poles

SURGE PROTECTION

Common mode surge protection up to 10KV.

FLUX EMISSION

The luminaire has luminous flux emission fully programmable directly from the product driver.

LED POWER VERSIONS

Monochromatic LED power versions with reflectors in silver Aluminium.

Iguzzini UFO - Street Light

NO RISK

No photobiological risk. This luminaire is in the “Exempt Group” (no risk linked to infrared, blue light and UV radiation) in accordance with EN 62471:2008.

CONTROL SYSTEM

An active control system modifies the current intensity to preserve the luminous efficacy and the lifetime of the LEDs under any ambient temperature conditions.

ROAD OPTICS

3 fixed profiles and one variable profilefor different output lumen levels and different powers :

- Profile 1 fixed to 350mA
- Profile 2 fixed to 450mA
- Profile 3 fixed to 525mA
- Profile 4 variable to 350mA

LIGHT FLOW

No upward emission of light flow

SCREWS

All external screws are in stainless steel.

MATERIALS USED

-Aluminium -Glass -Opaline polycarbonate -Silicone -Steel

OPTICS

-High performance optics Opti - Smart) -Uniform lightdistribution

COMPATIBILITY

-Compatibility with telemanagement systems thanks to “Power Supply” -Dual-operation Flux regulator and “LED Driver DALI” (0-10V/1-10V) compatible with the systems on the market.

ASSEMBLY

-Die-cast aluminium optical assembly -Sodium-calcium sealing glass or in opaline polycarbonate for versions with SC optic -Siliconed to frame that closes the LED compartment with screws
