RDFO6XT FACY LIGHTING

Spectrum Lighting Rdfo6xt Facy Lighting

RDFO6XT FACY LIGHTING

6" ROUND DOWNLIGHT - 5000LM


Two-stage optical system with regressed Solite lens for smooth light distribution.

Quick change LED module with interchangeable optics for job site adjustment and fixture maintenance. Shallow plenum design. Tool-less driver and j-box access. Posi-lock trim retention torsion springs.

Spectrum Lighting Rdfo6xt Facy Lighting

INFORMATION

APERTURE

6 In.

CRI

-83 CRI -98 CRI

VOLT

- 120V
- 277V

LAMP SOURCE

LED

TRIM TYPE

-Decorative Elements -Flange

CCT

- 2700k
- 3000k
- 3500k
- 4000k

USE

Interior lighting

PRODUT NO

5000LM

CHARACTERISTICS

- Round Shape
- Downlight
- Led
- Dimmable

Spectrum Lighting Rdfo6xt Facy Lighting

DISTRIBUTION

- Medium
- Narrow
- Very Narrow
- Very Wide
- Wide

DIMMING PROTOCOL

- 0-10v
- DALI
- DMX
- ELV
- Forward-Phase
- MLV

APPLICATION

Illumitech decorative recessed series offer two lengths of decorative acrylic cylinder (FACY). Cylinder glows softly to create ambiance.

TRIM FINISH

Decorative cylinder is soft etched UV stabilized cast machined acrylic. Matte White flange is standard.

CONSTRUCTION

Housing/frame constructed of #20 ga. galvanized steel to resist corrosion. Self-Flanged one piece trim spun from 0.063" thick high purity aluminum and finished to specification.

LUMENS

- 1000 Lm
- 1300 Lm
- 2000 Lm
- 3000 Lm
- 4000 Lm
- 5000 Lm

Spectrum Lighting Rdfo6xt Facy Lighting

RATINGS & COMPLIANCE

- Buy American Act
- LM79
- LM80
- Made in America
- Non-IC
- TM21
- Wet

FEATURES

Two-stage optical system with regressed Solite lens for smooth light distribution. Quick change LED module with interchangeable optics for job site adjustment and fixture maintenance. Shallow plenum design. Tool-less driver and j-box access. Posi-lock trim retention torsion springs.

CODE COMPLIANCE

BAA Compliant. ETL certified to meet US and Canadian standards. Suitable for dry or damp locations. Manufactured and tested to UL standards No. 1598/8750.

ELECTRONICS

LED system features Xicato LED module with proprietary phosphor technology that provides consistent, stable color with CCT control of +/- 100K over life of the light engine. Base CRI is 83 with 2-step MacAdam Ellipse binning. High CRI is 98 with 1x2-step MacAdam Ellipse binning. Variety of electronic 120V/277V and dimming drivers
