Speclight C0310xt 3" Round Direct - Ceiling Mount

C0310XT 3" Round Direct - Ceiling Mount

Speclight C0310xt 3\

C0310XT 3" ROUND DIRECT - CEILING MOUNT

3" round x 10" high mini cylinder luminaire for accent and general illumination. Spectrum’s Cylinder series provides traditional architectural style with high performance and energy efficient illumination.

Rugged design with flexible mounting, finish and LED options make these extremely versatile fixtures. Quick change LED module with interchangeable optics for job site flexibility and fixture upgrade.

Speclight C0310xt 3\

information

RATINGS & COMPLIANCE

- Buy American Act
- Made in America
- Wet

DIMMING PROTOCOL

- 0-10v
- ELV
- MLV
- DMX

APPLICATIONS

Commercial

APERTURE

3 in.

USE

Interior Lighting

LAMP SOURCE

LED

CCT

- 2700k
- 3000k
- 3500k
- 4000k

CHARACTERISTICS

- Accent luminaires
- General illumination luminaires

CRI

- 83 CRI
- 98 CRI

LUMENS

- 700 Lm
- 1000 Lm

SHAPE

Round

DOWNLOADS

↓ Specsheets

CONSTRUCTION

Fabricated seamless aluminum fixture housing. Specular primary optics provide high efficiency illumination. Stainless steel hardware with galvanized brackets to resist
corrosion.

APPLICATION

3" round x 10" high mini cylinder luminaire for accent and general illumination.

FINISH

Multi-stage polyester powder-coat process applied on our dedicated paint lines. See mounting and color pages for standard finishes. All exposed materials are chromate pretreated to resist corrosion

FINISHIES

- White
- Black
- Silver

Speclight C0310xt 3\
Speclight C0310xt 3\
Speclight C0310xt 3\

FEATURES

Spectrum’s Cylinder series provides traditional architectural style with high performance and energy efficient illumination. Rugged design with flexible mounting, finish and LED options make these extremely versatile fixtures. Quick change LED module with interchangeable optics for job site flexibility and fixture upgrade

CODE COMPLIANCE

BAA compliant. ETL certified to meet US and Canadian standards. Suitable for dry or damp locations. Wet Location Option. Manufactured and tested to UL standards No. 1598/8750.

DIMENSIONS

Speclight C0310xt 3\

ELECTRONICS

LED system features Xicato LED module with proprietary phosphor technology that provides consistent stable color with CCT control of +/- 100K over life of the light engine. Base CRI is 83 with 2-step MacAdam Ellipse binning. High CRI is 98 with 1 x 2-step MacAdam Ellipse binning. Variety of electronic 120V/277V and dimming drivers
