Spectrum Lighting Tx1303ledgv, Tx1604ledgv, Tx1905ledgv Wall, Ceiling Lights
TX1303LEDGV, TX1604LEDGV, TX1905LEDGV WALL, CEILING LIGHTS
TX1303LEDGV, TX1604LEDGV, TX1905LEDGV WALL, CEILING LIGHTS
Etched Triplex Italian Glass - 2700 Lm
Clear inner layer, opal center, etched outer layer for soft diffused lighting. Integral aluminum heat sink dissipates heat. 50,000 hours rated LED system life. Wall, ceiling, or pendant mounting.
INFORMATION
PRODUCTION
Made in America
LAMP SOURCE
LED
CCT
- 2700k
- 3000k
- 3500k
- 4000k
ELECTRONICS
GV LED system features high brightness white Samsung LED’s. 3 step MacAdam Ellipse binning. Standard CRI: 85+. Higher CRI, R9 and custom LED configurations are available; consult factory. Variety of electronic 120V/277V and dimming drivers.
RATINGS & COMPLIANCE
- ADA
- Buy American Act
LUMENS
- 1500 Lm
- 2700 Lm
CRI
85 CRI
SHAPE
Round
APPLICATION
Piazza TX Series Italian Triplex glass LED surface luminaire for decorative area lighting.
FINISH
Multi-stage polyester powder-coat process applied on our dedicated paint lines. See mounting and color pages for standard finishes.
DIMENTIONS
DIMMING PROTOCOL
0-10v
DOWNLOAD
↓ Data Sheet
CONSTRUCTION
Fixtures are spun in our factory from 0.063 high purity aluminum. Passive aluminum heatsink for optimal thermal management. Glass made in Italy, fixture made in the USA.
FEATURES
Clear inner layer, opal center, etched outer layer for soft diffused lighting. Integral aluminum heatsink dissipates heat. 50,000 hours rated LED system life. Wall, ceiling, or pendant mounting.
CODE COMPLIANCE
ARRA Compliant. ETL listed for damp locations. ADA Compliant, excluding: TX1905LEDGV. Manufactured and tested to UL Standard No. 1598/8750.
FINISHES
TIER 1 - STANDARD FINISHES
TIER 3 - SPECIAL METAL FINISHES
TIER 2 - TYPICAL FINISHES
