Louis Poulsen LP Nest Outdoor Light
LP NEST OUTDOOR LIGHT
LP NEST OUTDOOR LIGHT
ByStrup Arkitekter & Designers
The fixture emits an indirect, soft and symmetrical light. Reflections in the “lattice” create an attractive play of light within the fixture.
DESIGNER
BYSTRUP ARKITEKTER & DESIGNER
The company was established in 1994 by Erik Bystrup. Erik Bystrup completed his architectural studies in 1968 and worked for Krohn & Hartvig Rasmussen and with Johann Otto von Spreckelsen, among others, before starting his own studio.
Bystrup Architects have worked with architecture at all levels, from designing motorway bridges to development planning and urban strategies. When viewing their work, one is struck by the element of human empathy.
They are very were aware of the location and commission, and very sensitive to the opportunities for life, movement and experiences that can be created. A fine poetic band flows throughout the studio's practice. A consistent celebration of light, the seasons and natural elements.
The studio succeeds in transforming the architects' dreams into concrete realities which help realise the user's dreams. Soberly, where appropriate, and sensually effervescent when called for. It is as if practical considerations and function go hand-in-hand with a fairy tale narrative.
The design is simple and easy to grasp, yet agile and sculptural at the same time, breaking boundaries and creating new models. Playing with forms and adding value to what already is – whether this be a vibrant, changeable city or an open landscape.
Bystrup Architects have received several awards for their work, including the Norwegian Architecture Prize and the City of Copenhagen prize for good construction. Bystrup Architects developed the LP Nest post in cooperation with Louis Poulsen.
DESIGN TO SHAPE LIGHT
Louis Poulsen has always sought, not only to design lamps, but also to shape light and create an atmosphere that makes people feel good, both in- and outdoors. The shape of light creates space and our products should live harmoniously within the space they define - indirect, soft and inviting.
INFORMATION
MATERIALS
- Frame and Louvre : High Pressure Moulded Aluminium.
- Top Shade : Spun Aluminium.
- Reflector : Anodised aluminium.
- Enclosure : Clear glass.
CLASS
- Ingress Protection IP66.
- Electric Shock Protection I w. Ground, II w/o Ground. IK09.
SPECIFICATION NOTICE
-AJ 50 Wall has a LED light source that can be connected directly to the main power supply. -All LED efficiency information are measured as system power.
MOUNTING
- Pole Dimension : Ø 115mm Installation.
- Cable : 5m, 5x1mm2 (Class I) or 5m, 4x1mm2 (Class II).
- Driver : Location in the post top.
FINISH
Aluminium coloured with textured surface or graphite with textured surface, powder coated.
ENVIRONMENTAL PRODUCT SPECIFICATION
This product is compliant with the requirements contained in the European Directives, RoHS Directive 2011/65 and 2015/863. This product is designed so that 100% of the product can be disassembled and reused.
LIGHT SOURCE
- Light source LED 3000K 34W
- Lumen : 2842
DOWNLOAD
↓ Data Sheet
DIMENSIONS
- Width : 750 mm
- Height : 330 mm
- Length : 750
- Weight : Max 12.1 kg
DETAILS
Poles must be ordered separately. Mounting for pole Ø 115. For LED replacement kit please do contact Louis Poulsen. Dimming options CLO, and night time dimming (default setting: 50% power in 8 hours). All variants available with Zhaga socket for Smart City compatibility. Including CLO and night time dimming options. Driver: Location in the post top. Please contact Louis Poulsen for 2700K and more info about supported Light Management Systems.
THE STORY BEHIND THE PRODUCT
LP Nest was launched in 2010 and was designed by Bystrup Design. The designer was tasked with designing a post light focusing on technical requirements such as cut-off criteria and glare-free lighting, as well as aesthetic aspects. The idea was to take inspiration from structures in nature.
Erik Bystrup explains LP Nest as follows: ‘The lamp shade grows out of the cool steel trunk like a stylistic tree crown. A filigree pattern that imitates winter´s beautiful denuded trees as it gently lifts a disc of life-giving light. The design takes into consideration the development of new light sources, as the light can function irrespective of which light source ends up being the popular choice in future. The LED version was launched in 2011.
PRODUCT VARIANTS - LIST VIEW
| COLOUR | LIGHT SOURCE | LUMEN | CLASS | LIGHT CONTROL | VARIANT NUMBER | |
|---|---|---|---|---|---|---|
| Aluminium Colour Texture | LED 3000K 34W | 2842 | I | Dac: Dali + Clo | 5747305490 | |
| Aluminium Colour Texture | LED 3000K 34W | 2842 | II | Dpc: Nightdim + Clo | 5747305539 | |
| Graphite Grey Texture | LED 3000K 34W | 2607 | I | Dac: Dali + Clo | 5747305500 | |
| Graphite Grey Texture | LED 3000K 34W | 2607 | II | Dpc: Nightdim + Clo | 5747305542 | |
| Graphite Grey Texture | LED 3000K 34W | 2607 | I | Sr 2xzhaga Ct | 10000152323 | |
| Aluminium Colour Texture | LED 4000K 34W | 2915 | I | Dac: Dali + Clo | 5747305513 | |
| Aluminium Colour Texture | LED 4000K 34W | 2915 | II | Dpc: Nightdim + Clo | 5747305555 | |
| Aluminium Colour Texture | LED 4000K 34W | 2674 | I | Dac: Dali + Clo | 5747305526 | |
| Graphite Grey Texture | LED 4000K 34W | 2674 | II | Dpc: Nightdim + Clo | 5747305568 |
