LUN-UP EVO IN-GROUND UPLIGHT

Iguzzini Lun-up Evo In-ground Uplight

LUN-UP EVO IN-GROUND UPLIGHT

Floor/ground-mounted recessed luminaire intended for use with power monochrome LED light sources.  Supplied with high definition “OptiBeam” reflectors in metallised thermoplastic material with Flood and Wide- Flood optics.

Iguzzini Lun-up Evo In-ground Uplight

INFORMATION

BRAND

Iguzzini

PRODUCT TYPE

Ground Up Light

Iguzzini Lun-up Evo In-ground Uplight

BLUETOOTH ENERGY

The BLE - DALI interface means that all DALI products can be managed via Bluetooth Low Energy

APPLICATIONS

- Indoor
- Outdoor

LIGHTING EFFECTS

- Flood
- Wide- Flood

PRODUCTION

Made in Italy

TEMPERATURE

<40 °C

Iguzzini Lun-up Evo In-ground Uplight

USE

In-ground luminaires

STATIC LOAD RESISTANCE

2000Kg

INSTALLATION

Recessed installation on ground/ floor using the specific frame casing.

TYPES OF LIGHTING

LED

MATERIAL

Steel & Glass

COLOR

Black

Iguzzini Lun-up Evo In-ground Uplight

FRAME

Plastic frame for floor/ground installation with top closure cap; the package includes a joint for connecting two or more consecutive frames.

POWER SUPPLY

Monochrome version with 24Vdc electronic circuit, neutral white or warm white LED and power supply to be ordered separately.

FINISH

Product-frame connection is ensured by two captive screws in A2 stainless steel.

BODY

Comprising a body and frame casing to be ordered separately, with a 1/4 circle shape.

Iguzzini Lun-up Evo In-ground Uplight

DETAIL

Body in high performance, black PPS (polyphenylene sulphide) thermoplastic material; tempered sodium-calcium sealing glass with customized black silk-screen printing, 8 mm thick, mounted with silicon on a stainless steel plate with self-securing inserts; the glass + plate unit combines perfectly with the body thanks to stainless steel nuts and a silicone gasket insert.

CABLES AND CONNECTOR

In the lower compartment, the product is complete with a plastic PG9, multipolar cable L = 350mm with anti-transpiration device with quick coupling suitable for cables having a diameter D = 7 ÷ 13mm; a 3-way male/female branch connector and IP68 male connector are available as accessories for through-passing wiring.
