FLINDT PLAZA STREET LIGHT
FLINDT PLAZA STREET LIGHT
Designed by Christian Flindt
The fixture emits a glare-free downward directed light.
The light source is hidden at the top, inside the asymmetric carving on the side of the post, where the gradient serves as a reflector that softens the light and forms a pleasant organic shape on the ground below.
To optimise the flexibility in the lighting design, the illumination is adjustable with plus/minus 5° vertical and 360° horizontal, allowing for a more varied light distribution. The fixture is based on a modular principle and can in some configurations be built with up to five highly flexible light heads on one pole.
DESIGNER
CHRISTIAN FLINDT
Christian Flindt (1972-) graduated with an MAA and MDD from Aarhus School of Architecture in 2002. He then started his own design company in 2003.
Here, he placed high emphasis on communication between people, and his focus on this area finds expression in his approach to re-evaluating furniture. He wants his furniture to inspire people to make new connections.
Christian Flindt’s fresh and daring designs in conventional constructions prove that he is a designer with the courage to experiment. He develops innovative furniture and through his work with LED design, for example, he succeeds in blending disparate fields such as lighting and furniture design.
Christian Flindt began working with Louis Poulsen in 2006, since when he has developed the Flindt Bollard, the LP Xperi, the LP Grand, and the Flindt Wall. The latter won the Danish Design Award in 2019.
Christian Flindt is also known for his sculptural and rightfully praised chairs: Orchid, Ripple Chair and Light Lounger. He has held exhibitions and participated in trade fairs all over the world, and has been awarded a string of prizes including: the Bo Bedre Design Award 2005 and the Bolig Magasinet Design Award for the Flindt range he created for Louis Poulsen, the States Art Foundation Kunstfonds three year workgrant in 2012, the Knud V.
Engelhardts Memorial scholarship in 2013, the ELFORSK Price in 2014 by the Danish Department of Energy and Electricity with "Flindt Bollard" for Louis Poulsen, and in 2015 the Kold Christensens honorary scholarship.
INFORMATION
ENVIRONMENTAL PRODUCT SPECIFICATION
This product is compliant with the requirements contained in the European Directives, RoHS Directive 2011/65 and 2015/863. This product is designed so that 100% of the product can be disassembled and reused.
DOWNLOAD
↓ Environment Specification
USE
Outdoor lighting
SIZES (WIDTH X HEIGHT X LENGTH)
- Light module: 140 x 500 x 140 mm
- Pole 1 : 140 x 2500 x 140 mm
- Pole 2 : 140 x 3500 x 140 mm
- Pole 3 : 140 x 4500 x 140 mm
- Top : 140 x 150 x 140 mm
- Spacer : 140 x 500 x 140 mm
WEIGHTS
- Light module : Max 6.9 kg
- Pole 1 : Max 21.0 kg
- Pole 2 : Max 27.0 kg
- Pole 3 : Max 35.0 kg
- Top : Max 1.6 kg
- Spacer :Max 4.5 kg
CHARACTERISTICS
Based on a modular principle. A complete fixture is built up by single item numbers and consists of a pole, a top, an installation cable plus a number of light heads. (Maximum of 5 units on a pole. A unit can also be a spacer).
APPLICATIONS
- Public
- Residential
- Hotel
- Cultural
- Educational
- Retail
DETAILS
Driver integrated in each head. Surge protection device (SPD) not included. LED replacement kit available. Dimming options: DALI, CLO, and night time dimming (default setting: 50% power in 8 hours). All variants available with Zhaga socket for Smart City compatibility. Including CLO and night time dimming options. Please contact Louis Poulsen for more info about supported Light Management Systems.
Honeycombe available as an accessory which can be installed subsequently. Please note, Flindt Plaza is based on a modular principle. A complete fixture is built up by single item numbers and consists of a pole, a top, an installation cable plus a number of light heads. (Maximum of 5 units on a pole. A unit can also be a spacer).
MATERIALS
- Top: Cast aluminium.
- Head: Cast aluminium.
- Post: Extruded aluminium.
- Base plate: Cast aluminium.
- Diffuser: Polycarbonate.
MOUNTING
- Driver position: Driver integrated in each head.
- Posts available for inground installation or with base plate for surface mounting.
- Post diameter: Ø140mm.
- Fixture heads connects together with connectors and can be mounted on top of each other and fixed with two screws.
- Up to five heads on one post depending on total height.
- Reflector can be tilted +/- 5 degress from outside the fixture, and heads can be turned 360 degrees.
- Looping: Heads are connected by smart connectors.
- Installation cable: 5m 5x1mm² (Class I) or 5m 4x1mm² (Class II).
THE STORY BEHIND THE PRODUCT
The Flindt Plaza is an addition to the Flindt family, developed by award winning Danish designer and architect Christian Flindt, in collaboration with Louis Poulsen. The Flindt Plaza meets the need for scenic and flexible, as well as discreet, larger scale illumination in a range of applications from public parks, urban squares, city centres and ocean fronts.
The aesthetic design has the same subtle sculptural appearance as the rest of the Flindt family, complementing both modern and classic urban spaces. Based on the same design language and basic idea, one single asymmetric carving opens up for the light.
The distinctive carving gives the luminaire character, while also serving as a dimming reflector, softening the light and making it more pleasant in the dark of night, while also directing it precisely where needed.
The idea behind the sculptural design, however, was born in 2011, when a more refined type of bollard was desired to illuminate a park next to an exhibition at the Danish art hall Kunsthal Brænderigården in Jutland, today known as Viborg Kunsthal.
The fixture was so well received that Louis Poulsen decided to develop it further, together with Christian Flindt. The bollard was optimised in terms of material quality, light distribution and efficiency and was introduced as the Flindt Bollard at the Light + Building trade fair in Frankfurt in 2014.
The simple aesthetics of the resilient bollard, together with the functional and pleasant illumination, have since made the Flindt Bollard a convincing choice - elegantly complementing urban parks, and other public spaces during the day as well as making them more accessible and safe at night. Building on the success of Flindt Bollard the Flindt Plaza is an additional step to bring the Flindt family into applications where greater heights, scale and scenic illumination are required.
