FLAGO WARDROBE
FLAGO WARDROBE
Design by Officinadesign Lema
Bespoke wardrobe with hinged doors: minimalist with character.
The doors - available in glossy or matt lacquered finish - are defined by the sleek lines of the handles, in bronze-plated anodised aluminium or lacquered in the same colour as the doors.
There is a simple feel to the Flago Armadio al Centimetro from Officinadesign Lema.Versatile and customisable in terms of height, width and depth, Flago is a bespoke wardrobe with hinged doors and is also available in a corner version.
There is also plenty of scope to customise the interior: the Armadio al Centimetro programme offers a range of different finishes and stunning features design to allow the space to be adapted to accommodate specific functional requirements. These include drawers, racks for trousers, belts and shoes, shelves and clothes rails with integrated lighting solutions. The wardrobe also offers gorgeous detailing in leather and fabric, such as drawer pads and boxes for shirt racks.
INFORMATION
INTERNAL FRAME SIDE
-Material: Aluminium
-Thickness: 25 mm
-Frame finish: metal painted bronze epox M421, metal painted sand epox M455
HINGE
-Standard 94°
-Optional 165°
DOWNLOADS
↓ Data Sheet
↓ Catalogues
STRUCTURAL SUPPORTS FOR BACK PANEL
-Material: Hexacore AL PU panel, in narrow cell aluminum honeycomb with resistance to high vertical / horizontal torsion -Thickness: 10 mm
HANDLE FINISHES
- Metal painted bronze epox M421
- Metal painted palladio M491
- Metal painted matt LCT
VARIATION: MELAMINE
-Material: melamine particle board composed principally of poplar and fir CARB ATCM PHASE II / U.S. EPA TSCA Title VI
-Thickness: 25 mm
-Finish: gobi, sahara, canvas, lino, visone, larice sbiancato, larice moka
-Visible edge: ABS 10/10
OPENING SYSTEM
Hinged
DESIGNER
Officinadesign Lema
VARIATION: MATT LACQUERED LCT
-Material: MDF particle board faced with tupan CARB ATCM PHASE II / U.S. EPA TSCA Title VI
-Thickness: 25 mm
-Finish: matt lacquered LCT
-Visible edge: ABS 10/10
-Non-visible edges: single-ply paper 4/10
GLASS
All the transparent, acid-etched, back-painted, bronze and fritted glass is tempered. Any mirror glass is not tempered but has integrated safety film.
BACK PANEL
-Material: melamine particle board composed principally of poplar and fir CARB ATCM PHASE II / U.S. EPA TSCA Title VI
- Thickness: 8 mm
-Finish: melamine (canvas, lino, visone, larice sbiancato, larice grigio, larice moka), decorative fabric covering
GLASS BACK PANEL
-Material: tempered glass
-Thickness: 4 mm
-Finish: transparent, grey smoke, reflecting bronze
GLASS EXTERNAL SIDE
-Glass Thickness: 4 mm
-Thickness: 33 mm
-Frame finish: metal painted bronze epox M421, metal painted sand epox M455
-Finish: transparent, grey smoke, reflecting bronze
-Material: supporting frame in aluminium with closure panel in tempered glass
METALS
The metal components of the system (structure, doors, handles, steps) can have an anodized or epoxy powder coated finish, according to the type of product.
TILTED FIXED WOODEN SHOE RACK SHELF
-Thickness: 35 mm
-Material: melamine panel composed of wood particles, mainly poplar and fir CARB ATCM P
HASE II/U.S. EPA TSCA TITLE VI with heel stop profiles in painted aluminium
-Finish: melamine (larice grigio, visone, larice moka) bronze epox M421 melamine (lino, canvas, larice sbiancato) sand epox M455
FIXED GLASS SHOE RACK SHELF
-Material: transparent tempered glass with frame in painted aluminium
-Finish: bronze epox M421, sand epox M455
-Thickness: 35 mm
FINISHING PROFILE
In addition to the external side
-Material: covered MDF panel composed of wood particles CARB ATCM PHASE II/U.S. EPA TSCA TITLE VI
-Thickness: 12 mm
-Finish: matt lacquered LCT Wood (carbone oak, grey oak, heat-treathed oak, L-walnut)
SHELF IN SYNTHETIC LEATHER
-Material: moka colored synthetic leather with 3 mm thickness MDF support and frame in painted aluminium
-Finish: bronze epox M421, sand epox M455
-Frame thickness: 35 mm
MAT
-For extractable trays, display cases and grilles for small objects. -Material: moka colored synthetic leather with MDF support -Thickness: 6 mm -MDF support thickness: 3 mm
VARIATION: GLOSSY LACQUERED LCL
-Thickness: 25 mm
-Finish: glossy lacquered LCL
-Visible edge: ABS 10/10
-Non-visible edges: single-ply paper 4/10
-Material: MDF particle board faced with tupan CARB ATCM PHASE II / U.S. EPA TSCA Title VI
GLASS SHELF
-Material: transparent tempered glass with frame in painted aluminium -Finish: bronze epox M421, sand epox M455 Tempered glass thickness: 6 mm -Frame thickness: 35 mm
VARIATION: WOOD
-Thickness: 25 mm
-Finish: carbone oak, heat-treathed oak, L-walnut
-Visible edge: wood 10/10
-Non-visible edges: wood 10/10
-Material: MDF panel composed of wood particles CARB ATCM PHASE II/U.S. EPA TSCA TITLE VI
EXTERNAL SIDE
-Thickness: 25 mm
-Material: melamine particle board composed principally of poplar and fir CARB ATCM PHASE II / U.S. EPA TSCA Title VI
-Finish: melamine (canvas, lino, visone, larice sbiancato, larice grigio, larice moka) Matt lacquered LCT/glossy LCL Wood (carbone oak, grey oak, heat-treathed oak, L-walnut) Visible edge: ABS 10/10 according to the finishes
EXTERNAL FINISHING SIDE
-Material: MDF panel composed of wood particles CARB ATCM PHASE II/U.S. EPA TSCA TITLE VI
-Thickness: 14 mm with variable geometry terminal to compensate for door thickness
-Finish: matt lacquered LCT/ glossy LCL, wood (carbone oak, grey oak, heat-treathed oak, L-walnut)
-Visible edge: ABS 10/10 according to the finishes
BASE/TOP
-Material: melamine panel composed of wood particles, mainly poplar and fir CARB ATCM PHASE II/U.S. EPA TSCA TITLE VI -Thickness: 25 mm -Finish: melamine (canvas, lino, visone, larice sbiancato, larice grigio, moka) -Visible edge: wood or ABS 10/10 according to the finishes
INTERNAL SIDE
-Material: melamine panel composed of wood particles, mainly poplar and fir CARB ATCM PHASE II/U.S. EPA TSCA TITLE VI -Thickness: 25 mm Finish: melamine (canvas, lino, visone, larice sbiancato, larice grigio, moka) -Visible edge: wood or ABS 10/10 according to the finishes
SHELF
-Material: melamine panel composed of wood particles, mainly poplar and fir CARB ATCM PHASE II/U.S. EPA TSCA TITLE VI -Thickness: 35 mm -Finish: melamine (canvas, lino, visone, larice sbiancato, larice grigio, moka) -Visible edge: wood or ABS 10/10 according to the finishes
TECH SHELF
-Material: melamine panel composed of wood particles, mainly poplar and fir CARB ATCM PHASE II/U.S. EPA TSCA TITLE VI with front painted in aluminium -Finish: melamine (larice grigio, visone, larice moka) bronze epox M421 melamine (lino, canvas, larice sbiancato) sand epox M455 -Frame thickness: 35 mm
PLINTH
-Material: covered MDF in melamine CARB ATCM PHASE II/U.S. EPA TSCA TITLE VI
-Thickness: 25 mm
-Finish: melamine (canvas, lino, visone, larice sbiancato, larice grigio, moka) Matt lacquered LCT/glossy LCL Wood (carbone oak, grey oak, heat-treathed oak, L-walnut) Painted bronze epox M421 (for frame side) Painted sand epox M455 (for frame side)
CHEST OF DRAWERS
-Material: melamine panel composed of wood particles, mainly poplar and fir CARB ATCM PHASE II/U.S. EPA TSCA TITLE VI -Finish: melamine (larice grigio, visone, larice moka) bronze epox M421 melamine (lino, canvas, larice sbiancato) sand epox M455 -Thickness: 35 mm Front thickness: 19 mm Tempered glass thickness: 4 mm -Drawers internal finishing: melamine stone -Thickness: 14 mm
SHIRTS RACK/GRILLE FOR SMALL OBJECTS
-Resting on shelves or chest of drawers. -Material: melamine panel composed of wood particles, mainly poplar and fir CARB ATCM PHASE II/U.S. EPA TSCA TITLE VI -Finish: canvas, lino, visone, larice sbiancato, larice grigio, moka -Thickness: 10 mm
LIGHTING SYSTEM WITH HIGH LUMINOUS EFFICIENCY
-Low voltage LED lighting -Voltage: 24V (DC) -Color temperature: 3000 K -Efficacy: 135 Im/W -Lumen (1000 mm): 1060 Im -Lux (500 mm): 525 lx -Colour rendering index: CRI>80 -Power supply: 110V / 230V
-Hz: 50/60 Hz
COATING
-Oak: highly cross-linked acrylic coatings UV end urethane coatings (with no formaldehyde) containing no heavy metals (Pb, Cd, Cr). Due to its outstanding chemical and physical properties, this type of coating enhances the particular features of the wood, while retaining its original colouring and confering a delicate, soft-touch effect to the product. -Average opacity: Carbone oak Heat-treated oak Gray oak - 3 gloss -L- walnut: pre-tinted Canaletto walnut (American). Highly cross-linked acrylic coatings (with no formaldehyde) containing no heavy metals (Pb, Cd, Cr). Due to its outstanding chemical and physical properties, this type of coating enhances the particular features of the wood, while retaining its original colouring and confering a delicate, soft-touch effect to the product. -Average opacity: canaletto walnut - gloss 3
LACQUER
-Matt LCT: polyurethane paints with a high dry-matter content and containing no heavy metals (Pb, Cd, Cr). The pigments used for the lacquers are organic based with a high degree of light fastness. Polyamide beads with an average diameter of 30μm lend a pleasant roughness to the product and make it highly resistant to scratching.
-Average opacity: Sablè lacquered gloss 7-9 plain lacquered gloss 16-22 -Glossy LCL: coating with polyester undercoat. Lacquered with a brushed polyurethane coating for a high gloss finish: gloss >90.
CLAY
The top finish is of 100% clay particles applied using a spatulacoating process that confers uniqueness to the product. Any differences in the coloring or any lack of homogeneity should not be seen as a defect, but as a particular feature of the finish. The clay finish is protected by an acrylic coating and a transparent nanomolecular coating, which make the surface highly resistant to scratching and to chemical and food substances.
DESIGNER - OFFICINADESIGN LEMA
The simple aesthetics of the bespoke Ellevi wardrobe can be personalised from a wide range of finishes.
Officinadesign Lema is the design soul of Lema, a team of creatives and technical experts who translate in products and living spaces the philosophy and DNA of the brand. Officinadesign Lema develops new products integrating aesthetic research with technology.
Designing on one side single pieces for day and night areas; and on the other side different modular systems for the day area, from wardrobes to cabins, developing the Catalogue proposals and developing new projects, in direct contact with Piero Lissomi and external designers. To the designing activity the support to the sales force must also be counted through the perception of the brand image and the various layouts, as well as the development of materials for the catalogues and fabric selection which are always in line with the art direction.
CARE AND CLEANING
WOOD, MATT LACQUERED LCT, GLOSSY LCL, CLAY PANELS
For normal cleaning use a cloth moistened with water. For more thorough cleaning, use a neutral detergent.
METAL COMPONENTS
For routine cleaning, use a soft cloth moistened with water.
HINGES AND RAILS
Metal hinges and rails with high dynamic bearing capacity, equipped with 3D adjustments. Slowdown system integrated.
GENERAL INFORMATION
Clean the surface with a vacuum cleaner, without using any liquid.
GLASS AND MIRRORS
For routine cleaning, use a soft cloth moistened with water. For more thorough cleaning, use normal commercially available products. Do not use any abrasive products.
SAFETY
Carefully follow the assembly instructions. Do not modify the furniture in any way as this could render it unstable.
IMPORTANT
-Remove stains as soon as possible.
-Use a cloth or sponge to dry, do not rub.
-To clean the upholstery, use only a sponge or cloth but never a brush.
DISPOSAL
If product needs to be disposed of, please contact the local council or a private company authorized to dispose of bulk waste products.
FINISHES
PANEL TEXTILE DECORATIVE COATING/DOOR WOODS
HANDLE-METALS/EQUIPMENT-METALS
DOOR/GLOSSY LACQUERED LCL
DOOR-MATT LAQUERED LCT/MATT PAINTED METALS LCT-HANDLE
BACK PANEL/DOOR MELAMINE/EQUIPMENT/INTERNAL STRUCTURE
BACK PANEL/TEXTILE DECORATIVE COATING
