Simes Nanoled Walk-over Round Lights 30 mm

NANOLED WALK-OVER ROUND LIGHTS

Simes Nanoled Walk-over Round Lights 30 mm

NANOLED WALK-OVER ROUND LIGHTS

Nanoled Stainless Steel

Nanoled Inox is a recessed floor luminaire with reduced dimensions designed to create luminous paths and accent light of architecture and trees.

INFORMATION

BRAND

Simes

PRODUCT TYPE

Lights

PRODUCTION

Made in Itlay

COLLECTION

Nanoled

LUMINAIRE TYPE

Inground walk over fitting. Recessing depth 125 mm. IP rating IP 65 IP67

POWER

- Rated module power : 0.2W
- Rated luminaire power : 0.3W

STANDARD DEVIATION COLOR MATCHING

MacAdam step 3

LIGHT SOURCE TYPE

LED

COLOUR TEMPERATURE

4000K

LED LIFETIME

L80 B10 70.000h Ta 25°C L80 B10 50.000h Ta 40°C

LUMINAIRE EFFICACY

47lm/W

COLOR RENDERING INDEX

CRI 80

Simes Nanoled Walk-over Round Lights 30 mm

VOLTAGE (DC)

24Vdc

DIMMABLE

PWM

TEMPERATURE

- Storage temperature range : da -20°C a +60°C
- Performance ambient temperature : Tq 25°C
- Glass low surface temperature : 40°c (ta 25°c)
- Operating ambient temperature range : da -20°C a +50°C

Simes Nanoled Walk-over Round Lights 30 mm

POWER CABLE

5m - H05RN-F

MATERIAL

Stainless Steel

CAPACITY

500 kg

WEIGHT

0.7344Kg

LIFESPAN OF THE LUMINAIRE

Min. 50.000h Ta 40°C

MECHANICAL RESISTANCE

IK08

CLASS

- Electrical insulation class : III
- Protection class IP : IP65 IP67

MATERIAL CHARACTERISTICS

Body made of AISI 316L monoblock stainless steel. Absence of screws (the luminaire is fixed to the recessing box with OR rings). Recessing box in polypropylene. Mechanical resistance of diffusor IK 08

LIGHTING PERFORMANCE

Toughened trasparent or acid-etched glass. Lamp fixed position. LOR --

PWM FREQUENCY NB

<600Hz Do not use the Remote Power Supply operating at a frequency higher than that indicated

TECHNICAL DRAWINGS

Simes Nanoled Walk-over Round Lights 30 mm
Simes Nanoled Walk-over Round Lights 30 mm

RATED MODULE LUMINOUS FLUX

42lm

RATED LUMINAIRE LUMINOUS FLUX

14lm

TO MARK PATHS AND TO ENHANCE BUILDING

Nanoled Inox is a recessed in ground luminaire characterized by a compact design. It is offered in a wide variety of light beams that allow you to achieve both accent effects for the lighting of architectural details and to be used as a marker. Made of a single stainless steel piece, it is totally free from visible screws.

LED MODULE INCLUDED

This luminaire contains built-in led modules. In case of damage or malfunction please contact the manufacturer to receive additional instructions on how to replace and relative spare parts to order. The led modules cannot be handled in the luminaire by the end user. This product contains a light source of energy efficiency class: f.

LED modules are engineered accordingly to the existing regulations of Lumen Maintenance (LM80) and Technical Memorandum (TM21), where uniformity and quality of the light is 70,000 hours referred to L80 B10 Ta 25 ° C (50,000 hours referable to L80 B10 Ta 40°C). Lifespan of the luminaire min. 50,000 hours at 40°C. Performance Ambient temperature Tq 25°C. Operating ambient temperature range is from -20°C to +50°C. Storage temperature range from -20°C to +60°C.

RANGE

Nanoled stainless steel is available in different versions and applications. Access to the code list of the type of your interest.

Simes Nanoled Walk-over Round Lights 30 mm
Inground Walkover
Simes Nanoled Walk-over Round Lights 30 mm
Step Light Wall Recessed
Simes Nanoled Walk-over Round Lights 30 mm
Ceiling Recessed Mounted
