L&l Luce&light Srl

Lucelight Bright 1.b Outdoor Step Lights

BRIGHT 1.B OUTDOOR STEP LIGHTS

Lucelight Bright 1.b Outdoor Step Lights

BRIGHT 1.B OUTDOOR STEP LIGHTS

Step Lights For Outdoor Applications

step light for outdoor applications - 2,5W - 3,5W 24Vdc - radial optics - Ø39 mm - Six light beam configurations: 1x60°, 2x60°, 3x60°, 4x60°, 1x120°, 1x180°

Lucelight Bright 1.b Outdoor Step Lights

INFORMATION

BRAND

Lucelight

PRODUCT TYPE

Step Light Light

APPLICATIONS

Outdoor

Lucelight Bright 1.b Outdoor Step Lights

COLLECTION

Bright

POWER SUPPLY

24Vdc

POWER CONSUMPTION

-2,5W -3,5W

Lucelight Bright 1.b Outdoor Step Lights

NUMBER AND TYPE OF LED

- 1 power LED
- 1/4 ANSI BIN (white LED colour)
- 50 000h L90 B10 (Ta 25°C)

LED COLOURS

- 2700K
- 3000K
- 4000K
- Blue

POWER CABLES

Includes 1,5 m neoprene cable, h05rn-f 2x0,35/0,75 ø6,3 mm

LUMEN OUTPUT AT SOURCE

- 171 lm (3000K, 2.5W),
- 220 lm (3000K, 3.5W)

POWER SUPPLY UNIT

Power Supply Unit Not Included

DIMENSION

Lucelight Bright 1.b Outdoor Step Lights

DELIVERED LUMEN OUTPUT

- 38 lm (3000K, 4x60°, 2.5W),
- 56 lm (3000K, 4x60°, 3.5W)

BODY MATERIAL

Body And Trim In Aisi 316l Stainless Steel

MOUNTING

Recessed (Wall, Floor)

INSTALLATION

Step light for outdoor applications

CRI COLOUR RENDERING INDEX

80

FINISHES

Stainless Steel

Lucelight Bright 1.b Outdoor Step Lights

INGRESS PROTECTION

IP65, IP68

IMPACT RESISTANCE

IK08

WEIGHT

0,20 kg

CONTROL

Casambi Control

OPTICS

-Radial 1x60° -Radial 1x120° -Radial 1x180°-Radial 2x60° -Radial 3x60° -Radial 4x60°

Lucelight Bright 1.b Outdoor Step Lights
Lucelight Bright 1.b Outdoor Step Lights
Lucelight Bright 1.b Outdoor Step Lights

FEATURES

- CE mark for the European Union
- UKCA mark for Great Britain
- CB
- EAC
- BIS R-41105201
- Appliance Class Iii
- Walkover Fixture
- Intelligent Protection System
- Lighting fixture with led technology
- RAL finish on request
- Maximum Device Temperature50°c
- Energy efficiency class of the light source

Lucelight Bright 1.b Outdoor Step Lights
