Lamm Tulip Conference Chair

Tue Feb 27, 2024Easy ChairsSteelBartoli Design

TULIP CONFERENCE CHAIR

TULIP CONFERENCE CHAIR

Bartoli Design

INFORMATION

BRAND

Lamm

COLLECTION

Tulip

PRODUCT TYPE

Chair

RODUCTION

Made In Italy

SEAT AND BACKREST

Seat and arm tip-up mechanism made of die-cast aluminium and painted in the same colour as the beam. The device acts in a synchronized way: when the seat is lowered to be used, the arms are also dragged into the same position. Similarly, the closing takes place by means of a special device equipped with a gas spring, with a slow-down effect in the final stage of the closing. The return of the seat automatically closes the arms shared with other places only when they are not in use

TESTED

Tested according to European standards.

USE

Indoor

TYPOLOGIES

Armchair on beam with 2, 3 or 4 places, that can be connected in rows. 56 or 62 cm. centre to centre distance

ARM BASE

Also available on single base with double arm.

ROWS

Installation on horizontal and inclined flooring or on steps, in straight rows.

TECHNICAL FEATURES

Armchair for auditorium and conference halls.

BASE

Bearing base in tubular steel, completely covered with an ABS guard colour co-ordinated with the beam structure. During the assembly in rows, the support bases are positioned at regular distance according to the row aesthetic and functional requirements. Bases are designed for floor fixing and the anchoring is completely hidden under a guard.

STRUCTURE

Beam in scratchproof, semi-matt silver, semi-matt black RAL 9005 and embossed graphite-coloured tubular steel, with one, two, three or four places, that can be assembled in straight rows using connection joints inside the beam.

SEAT, BACKREST AND ARMS

Seat, backrest and arms with internal structure in tubular steel. Non-deformable, fla

ACCESSORIES

Tip-up writing tablet with anti-panic movement. Row identification and seat numbering elements.

DOWNLOADS

↓ Technical Data
↓ Dimension

DIMENSIONS

TULIP ON BEAM

TULIP

TULIP WITH SINGLE BASE

FEATUERS

COMFORT AND DESIGN

Designed to satisfy demanding functional and comfort requirements, this armchair is formally qualified by a compact, rounded contour which facilitates its inclusion in different architectural settings.

INNOVATIVE OPENING SYSTEM

When the seat is lowered, the arms are also brought down into the same position, thanks to the synchronised innovative opening system. The cushioned return of the seat also closes automatically the arms shared with other positions, only when they are not in use.

STRUCTURE AND MATERIALS

Seat, back and arms with tubular steel internal structure, padding in flame-retardant, cold-moulded, non-deformable polyurethane foam, with leather or fabric covering. Support beam in painted tubular steel, support base in tubular metal, covered with an ABS guard colour-coordinated with the beam.

VERSIONS

Beam-mounted single version with double arm, arranged in straight rows with floor fixed, load-bearing bases by means of an anchor foot covered by a painted ABS collar. Installation on horizontal and inclined floors or on steps, in straight rows.
