Forms + Surfaces

Forms+Surface Cordia Bollard Lights

CORDIA BOLLARD LIGHTS

Forms+Surface Cordia Bollard Lights

CORDIA BOLLARD LIGHTS

The Cordia Bollard's dynamic round-to-square profile and LED technology coordinates with the rest of the Cordia family.

INFORMATION

CONSTRUCTION

-Body is made from corrosion-resistant cast aluminum with a powdercoat finish. -Base is made from corrosion-resistant aluminum with a powdercoat finish.

Forms+Surface Cordia Bollard Lights

TEMPERATURE

3000K warm white and 4000K neutral white LED.

Forms+Surface Cordia Bollard Lights

LENS, VISIBILITY & SHIELD OPTIONS

- Includes an optically clear acrylic lens.
- Bollard emits light with a 360° visibility.
- Optional shield is available with 180° coverage.

BRAND

Forms+Surface

TYPE OF LIGHT

LED technology

WATTAGE

35W

WEIGHT

40 lbs.

Forms+Surface Cordia Bollard Lights

LED CHIP

ED chip is mounted to an extruded aluminum heat sink

Forms+Surface Cordia Bollard Lights

MAINTENANCE

Metal surfaces can be cleaned as needed Metal surfaces can be cleaned as needed and a mild detergent. Avoid abrasive cleaners.

PRODUCT TYPE

Bollard Lights

PRODUCTION

Made in United States

HEAD

Head consists of corrosion-resistant cast aluminum and a clear acrylic lens

Forms+Surface Cordia Bollard Lights

DRIVER

-LED driver input power is 100-270 VAC. -Driver has 0-10V dimming capabilites.

Forms+Surface Cordia Bollard Lights

INSTALLATION

-Bollards must be surface mounted using four tamper-resistant bolts. -Installation of a surge protector as part of each units wiring is recommended. -Stainless steel mounting hardware sold separately. Templates available upon request.

ENVIRONMENTAL CONSIDERATIONS

-Please refer to the Cordia Bollard Environmental Data Sheets for detailed environmental impact information. -Metal components have a long life cycle and are 100% recyclable. -Standard powdercoat finishes are no-VOC; non-standard powdercoat finishes are no- or low-VOC, depending on color. -Low maintenance; easy to disassemble.

TECHNICAL DRAWING

Forms+Surface Cordia Bollard Lights

RECYCLED

High recycled content; highly recyclable

CERTIFICATIONS

ETL and C-ETL listed for wet locations

COLORS

Forms+Surface Cordia Bollard Lights

RECYCLING TEXTURES

-Lime Texture -Azure Texture

COLOR TEXTURES

METALLIC TEXTURES

Forms+Surface Cordia Bollard Lights
Forms+Surface Cordia Bollard Lights

GLOSS COLORS

-Black Gloss -Bright Silver Gloss -Slate Gloss
