Landscape Forms Northport Bollard
NORTHPORT BENCH
NORTHPORT BENCH
Designed by Robert A.M. Stern
Created in collaboration with Robert A.M. Stern Architects, renowned authorities on Modern Traditional design, the Northport Collection spans the full breadth of site furnishing and lighting elements.
Encompassing benches, area and path lighting, litters, bike racks, planters and bollards, the collection offers a modern reinterpretation of the design lexicon that is foundational to so many traditional American towns and cities, historical centers, and main street districts.
Northport Collection bollards frame, define and protect installations with a handsome presence. The subtly tapered aluminum casting complements the curvature found throughout the collection and provides elegant cover for a robust steel ground connection.
Northport bollards can be surface mounted, embedded, or feature a removable aluminum casting.
INFORMATION
BRAND
Landscape Forms
PRODUCT TYPE
Bench
FINISH
Northport bollard is a cast aluminum form with a powdercoat finish.
EMBEDDED
- The steel post is set into an 18" concrete footing.
- A stainless steel ring helps align and aid installation.
- This is the strongest and most common method for installation.
- The steel post is slipped over the top of the post and locked into the base of the post with tamper-resistant set screws.
COLLAR
A steel post is bolted into the aluminum bollard via a stainless steel collar.
PRODUCTION
Made in U.S.A.
SOCKET
A galvanized socket is embedded in concrete.
FINISHES
-All metal is finished with Landscape Forms’ proprietary Pangard II® polyester powdercoat, a hard yet flexible finish that resists rusting, chipping, peeling and fading. -A wide range of standard, optional and custom colors are available.
MOUNTED
The removable version aesthetically matches embedded and surface mount versions.
SURFACE MOUNT
-An aluminum base plate is anchored to the concrete in three locations.
-The aluminum base plate helps align and aid installation. -3 stainless steel leveling glides allow installation to be perfectly “dialed-in” from the top side of base. -The aluminum bollard is slipped over the top of the base plate and locked into place with tamper-resistant set screws.
DOWNLOADS
↓ Data Sheet
MATERIAL
The steel post is inserted into the socket, and secured with a locking mechanism.
MOUNT
SPECIFY
Northport bollard and select powdercoat color and mounting option (embedded, removable, or surface mount)
DIMENSIONS
| STYLE | DEPTH (INCHES) | HEIGHT (INCHES) | WEIGHT (LBS) |
|---|---|---|---|
| Embedded | 8.5” | 36.5” | 52 lbs |
| Surface Mount | 8.5” | 36.5” | 38 lbs |
| Removable | 8.5” | 36.5” | 70.5 lbs |
DESIGNER - ROBERT A.M. STERN
Robert A.M. Stern is a wholly owned subsidiary of industry leader Robert A.M. Stern Architects, LLP. Working in the tradition of architects from Frank Lloyd Wright to Alvar Aalto, the firm designs products grounded in tradition and informed by the spirit of innovation, produced and marketed by leading manufacturer partners with outstanding reputations for quality, performance and service. The Concord site furniture collection for Landscape Forms reflects Robert A.M. Stern's commitment to design that is informed by the past and contemporary in spirit. The collection’s 'modern traditional' idiom expands Landscape Forms' vocabulary of design.
MATERIAL
NEUTRAL SERIES - POWDERCOATED METAL
VIVID SERIES - POWDERCOATED METAL
![Landscape Forms Northport Bollard](http://{"type":"application/jidipi-edit","data":"<figure class=\\"jdp-reset jdp-image-figure\\" data-ce-tag=\\"image-figure\\"><div class=\\"jdp-mask\\" data-ce-tag=\\"mask\\"><img src=\\"https://upload.jidipi.com/posts/d00096336/1-y9R.png\\" data-image-id=\\"65f140c03f7a0ad506f52fa9\\" srcSet=\\"https://upload.jidipi.com/fit-in/420x0/posts/d00096336/1-y9R.png 420w, https://upload.jidipi.com/fit-in/700x0/posts/d00096336/1-y9R.png 700w, https://upload.jidipi.com/fit-in/900x0/posts/d00096336/1-y9R.png 900w\\" data-image-name=\\"1.png\\" width=\\"914\\" height=\\"230\\" loading=\\"lazy\\" class=\\"jdp-image jdp-reset\\"/></div></figure>"})
ARCHITECTURAL SERIES - POWDERCOATED METAL
