Cangini E Tucci, S.r.l.

Cangini & Tucci Frequency applique Pendant Lamp

FREQUENCY APPLIQUE PENDANT LAMP

Cangini & Tucci Frequency applique Pendant Lamp

FREQUENCY APPLIQUE PENDANT LAMP

Frequency is a linear LED lamp made of blown glass and designed by Marcantonio. Frequency exists in two versions, both hanging. The first can be installed horizontally, over a dining table, above a reception desk or a desk in an office.

The second is installed vertically and works like a floor lamp, but without any obstacle on the ground, since it does not have a base. Frequency, like all Cangini and Tucci lamps, is entirely handmade in Italy.

“Frequency was born from the desire to enhance the essence of light. I imagined a beam of light that traveled through space. I wanted the shape of the glass to tell the movement and intensity of the energy released by this beam. Through a skilful control of the glass, thanks to the experience of Cangini and Tucci, we managed to create a sculptural object with a definite character but at the same time fluid and light, an object in which the shapes seem to interpenetrate, in which the volumes slide into each other as in a wave of living and active energy. Frequency is a contemporary lamp that celebrates the art of handmade glass as only a sculpture can do”.

Cangini & Tucci Frequency applique Pendant Lamp

INFORMATION

LUMINIUS FLEX

150,2 Lm/W - 540 mA

VOTLAGE

20 V

PRODUCT TYPE

Pendant Lamp

 TYPOLOGY

- Wall lamp
- Hanging Lamp

FEATURES

Through a skilful control of the glass, thanks to the experience of Cangini and Tucci, we managed to create a sculptural object with a definite character but at the same time fluid and light, an object in which the shapes seem to interpenetrate, in which the volumes slide into each other as in a wave of living and active energy. Frequency is a contemporary lamp that celebrates the art of handmade glass as only a sculpture can do”. Marcantonio

PRODUCT CODE

- AP1551
- 1553.VE
- 1553.OR.1
- 1553.OR.2
- MINI1553.V
- GIG1553.OR.2
- 1555.VE with shuko plug

Cangini & Tucci Frequency applique Pendant Lamp

CABLE

Coaxial low voltage electric cable in transparent.

DESIGN

EUIPO’s registered community design

METAL STRUCTURE FINISH AVAILABLE

- Chrome
- Satin Gold
- Satin Black Nickel.

LED AVAILABLE FOR FREQUENCY L63 CM

-LED 10,8 W DIMM - 1622 Lm - 150,2 Lm/W - 540 mA - CRI 95 - 20V - 2700°K or 3000°K  -Lumen indicated corresponds to the luminous intensity at the origin of the led light bar.  -LED 10,8 W DIMM - 675 Lm - 62,5 Lm/W - 540mA - CRI 95 - 20V - 2700°K or 3000°K  -Lumen luminous intensity with transparent glass.

DIMMABLE

Yes - LED is replaceable by the manufacturer.

ON DEMAND

With UL components for USA +10%

DRIVE

Driver Included.

CRI

CRI 95

WATTAGE

- GIG1553.OR.2 : 24.48
- MINI1553.VE / AP1551 / : 10.8 w
- 1553.OR.1 / 1553.OR.2 / 1555.VE /1555.VE : 21.6 w

DETAIL

Lumen indicated corresponds to the luminous intensity at the origin of the LED light bar.

LED AVAILABLE FOR FREQUENCY SUSPENSION L128 CM

-Lumen luminous intensity with transparent glass. -LED 21,6 W DIMM - 1350 Lm - 62,5 Lm/W - 1080mA - CRI 95 - 20V - 2700°K or 3000°K  -LED 21,6 W DIMM - 3245 Lm - 150,2 Lm/W - 1080 mA - CRI 95 - 20V - 2700°K or 3000°K -Lumen indicated corresponds to the luminous intensity at the origin of the LED light bar.

DIMM

- GIG1553.OR.2 : 677 Lm
- GIG1553.OR.2 : 677 Lm
- AP1551 /MINI1553.VE : 1622 Lm
- 1553.OR.1 m /1553.VE /1555.VE : 3245 Lm

LED AVAILABLE FOR FREQUENCY SUSPENSION L150 CM

-Lumen luminous intensity with transparent glass. -LED 24,48 W DIMM - 3677 Lm - 150,2 Lm/W - 1080 mA - CRI 95 - 20V - 2700°K or 3000°K   -Lumen indicated corresponds to the luminous intensity at the origin of the led light bar.  -LED 24,48 W DIMM - 2400-2600 Lm - 100-105 Lm/W - 1080mA - CRI 95 - 20V - 2700°K or 3000°K

STANDARD LIGHT

LED

TEMPERATURE

2700°K or 3000°K

teCHNICAL DRAWINGS

AP1551 WALL LAMP

- Length : 15 cm
- Picture : 21 cm
- Height : 70 cm

Cangini & Tucci Frequency applique Pendant Lamp

1553.OR.1 HANGING LAMP

- Length : 28 cm
- Picture : 17 cm
- Height : 17 cm

Cangini & Tucci Frequency applique Pendant Lamp

1553.OR.2 HANGING LAMP

- Length : 128 cm
- Picture : 17 cm
- Height : 17 cm

Cangini & Tucci Frequency applique Pendant Lamp

GIG1553.OR.2 HANGING LAMP

- Length : 150 cm
- Picture : 22 cm
- Height : 22 cm

Cangini & Tucci Frequency applique Pendant Lamp

MINI1553.VE HANGING LAMP

- Length : 15 cm
- Picture : 15 cm
- Height : 63 cm

Cangini & Tucci Frequency applique Pendant Lamp

1553.VE HANGING LAMP

- Length : 17 cm
- Picture : 17 cm
- Height : 128 cm

Cangini & Tucci Frequency applique Pendant Lamp

1555.VE WITH SHUKO PLUG HANGING LAMP

- Length : 17 cm
- Picture : 17 cm
- Height : 128 cm

Cangini & Tucci Frequency applique Pendant Lamp

FINISHES

GLASS COLORS

Cangini & Tucci Frequency applique Pendant Lamp

BICOLORED FINISH

Cangini & Tucci Frequency applique Pendant Lamp

METAL STRUCTURE FINISH

Cangini & Tucci Frequency applique Pendant Lamp
