DAYTONA STREET LIGHT

Dw Windsor Daytona Street Light

DAYTONA STREET LIGHT

All-round performance. All-round confidence.

Daytona balances style, efficiency and practicality to deliver a luminaire capable of maximising performance while providing outstanding service life to support the circular economy.

FEATURES

READY FOR CONTROLS

Daytona is compatible with the latest lighting control technologies via optional top and bottom sockets and external networking solutions with CMS integration, delivering additional energy savings.

Dw Windsor Daytona Street Light

FUTURE-PROOFED DESIGN

Daytona features replaceable light modules that can be upgraded to prolong service life and toolless entry to simplify installation and maintenance.

Dw Windsor Daytona Street Light

ADAPTABLE LIGHT

Daytona offers tunable white technology as standard, providing a dynamic night-time illumination for visual comfort, offering a sense of security and minimising the impact on flora and fauna.

Dw Windsor Daytona Street Light

INFORMATION

BRAND

Dw Windsor

PRODUCT TYPE

Street Light

COLLECTION

Daytona

PRODUCTION

Made in United Kingdom

Dw Windsor Daytona Street Light
Dw Windsor Daytona Street Light

TECHNICAL DRAWINGS

MATERIAL

-S
eals : Silicone
-Body : High-pressure die-cast aluminium (LM6)
-Glazing : Toughened glass (IK08) / Polycarbonate (IK10)
-Finish : Polyester powder coat / Marine grade coating

USE

Outdoor

WINDAGE

0.052m2

INSTALLATION & MAINTENANCE

- Available pre-wired
- Includes SupportTag for easy luminaire maintenance

ENHANCED URBAN LIVING

Daytona’s modern design, precision optics, and advanced features make it ideal for urban applications. Now Dark Sky approved, Daytona can help preserve the integrity of the night sky for sensitive locations.

Dw Windsor Daytona Street Light

COLOUR TEMPERATURE

2700K, 3000K and 4000K CCT options for high performance, up to 178lm/W

SOCKETS

Supports a range of nema and zhaga connectivity and control options via top and/or bottom sockets

WEIGHT

8.7kg

LIFETIME

100.000 hours L90 B10

Dw Windsor Daytona Street Light

STANDARD COLOURS

HOW IT WORKS

Luminaires include LEDs with two separate colour temperatures (e.g. 3000K and 2200K). When mixed, these can produce a range of colour temperatures. The system is easily and securely configured via Bluetooth using a smart device, either by directly setting the desired CCT and brightness or creating time-based scenes to dynamically change throughout the night.

SURGE PROTECTION

8kV

OPERATIONAL TEMPERATURE RANGE

–40°C to +40°C

TYPE OF LIGHT

LED

DOWNLOAD

↓ Data Sheet

ACCESSORIES

- Light shield - one side
- Light shield - two sided

Dw Windsor Daytona Street Light

APPLICATIONS

- Car Parks
- Urban Roadways
- Housing Developments
- Footpaths & Cycle Routes

LUMINAIRE EFFICACY

Up to 178lm/W

COLOUR RENDERING INDEX

70Ra

LUMEN OUTPUTS

- 8 LED : Up to 3.400lm
- 16 LED : Up to 6.670lm
- 24 LED : Up to 9.670lm
- 32 LED : Up to 14.170lm

CONNECTIVITY

-T
o support a wide range of connectivity and control options, including a selection of sensors and networking nodes, Daytona can be specified with both NEMA and Zhaga sockets mounted in top and bottom locations.

Dw Windsor Daytona Street Light

-By offering both standards, Daytona is not limited to a single product ecosystem and can adapt to new technologies as they are developed. This provides added flexibility and the opportunity to add functionality, now or in the future.

KEY ADVANTAGES

-F
uture-proofed lighting solution with replaceable light engines to facilitate future upgrades -Outstanding service life (100,000 hrs L90 B10) to support the circular economy -Toolless entry for easy luminaire maintenance, saving time and lowering costs -Tunable White technology improves visual comfort whilst minimising the impact to wildlife -Dark sky friendly with a 0% ulor rating plus optional light shields for additional light management

MOUNTING

- Direct post : Ø76mm
- Side entry : Ø34 - 42mm

DRIVE CURRENT

250mA - 1050mA (in 50mA increments)

TECHNICAL SPECIFICATION

Daytona lumen packages and wattages matrix

Dw Windsor Daytona Street Light

CONTROL

BLUETOOTH

Switch, dim and configure luminaires wirelessly for increased convenience and flexibility. Manage luminaires individually or in a group using scenes. Controlled directly from a smart device, no additional controls cabling required.

SENSORS

-D
aytona can accommodate a variety of sensors on the underside of the luminaire. Motion sensors can be used to provide increased energy savings by dimming when no movement is detected. -Alternatively, environmental detectors such as pollution or road temperature sensors can be integrated to report data as part of a Connected Spaces installation.

CONTROL OPTIONS

Lighting control systems offer many benefits, from increased flexibility to helping lower energy consumption. Daytona can be specified with multiple control options to suit the individual needs of your scheme.

Dw Windsor Daytona Street Light

DESIGN FEATURES

CMS / CONNECTED SPACES INTEGRATION

To allow our customers the greatest flexibility, we remain CMS agnostic and have supplied luminaries with all the current CMS and Connected Spaces platforms on the market.

With Daytona, we can fit internal nodes for all major systems minimising the visual impact on the lanterns aesthetic (an external aerial is still required). The following is a small selection of the control technologies we have installed in our lanterns:

- Urban Control
- Telensa
- Mayflower Smart Control

PHOTOCELLS AND PART NIGHT DIMMING

For a basic control option, pair Daytona with a miniature photocell for dusk-to-dawn lighting. To trim burning hours, we recommend a 20lux photocell to limit ‘on time’. To achieve greater energy savings, without the capital expenditure of a full CMS system, consider dimming your lanterns for part of the night. We can pre- program the driver to any regime for tailored energy savings.
