Tournesol Siteworks

Tournesol Urban Rectangle & Square Planters

URBAN RECTANGLE & SQUARE PLANTERS

Tournesol Urban Rectangle & Square Planters

URBAN RECTANGLE & SQUARE PLANTERS

Gfrc - Lightweight Concrete & Frp - Fiberglass

Sleek, simple, and elegantly tapered in design, Urban planters are available in FRP fiberglass and lightweight GFRC concrete. Urban planters are designed to be durable despite low weight, even for heavy-traffic locations.

INFORMATION

CONTAINER

Coordinates with our self-watering container irrigation products

BRAND

Tournesol

PRODUCT TYPE

Planters

FEATURE

FRP fiberglass and lightweight GFRC concrete planters are designed to be durable despite low weight

COLLECTION

Urban

USE

Outdoor

DURABLE

Durable Glass Fiber Renforced Concrete planters

Tournesol Urban Rectangle & Square Planters
Tournesol Urban Rectangle & Square Planters

SHAPES

- Round
- Square
- Rectangular

TECHNICAL DETAIL

DETAIL

PRODUCTSHAPELENGTHWIDTHHEIGHTWEIGHT

(LBS.)
VOLUME

(CUBIC FT.)
INTERIOR

TOP
INTERIOR

BOTTOM
IRRIGATION
UCRT-1800Square18"18"29"2003.814" x 14"11.5" x 11.5"CWM-R1114-MS
UCR-241824Rectangle24"18"24"1904.220" x 14"18.5" x 11.5"CWM-R1114-MS
UCR-2400Square24"24"27"1606.521" x 21"16.5" x 16.5"CWC-R1850/CWM-R1114-2K
UCRT-2400Square24"24"47"3001220" x 20"15" x 15"CWC-R1850
UCR-3000Square30"30"32"2601226" x 26"22.5" x 22.5"CWM-R2020-MS
UCRT-3000Square30"30"53"4501826" x 26"20" x 20"CWM-R2020-MS
UCR-361824Rectangle36"18"24"2506.632" x 14"30.5" x 11.5"CWM-R1114-2K
UCR-3600Square36"36"34"3702032" x 32"28" x 28"CWM-R2020-2K
UCR-481824Rectangle48"18"24"315944" x 14"42.5" x 11.5"CWM-R1614-2K
UCR-4800Square48"48"42"6654443" x 43"40" x 40"CWM-R2920-2K
UCR-601824Rectangle60"18"24"3751156" x 14"54.5" x 11.5"CWM-R2014-2K

OPTIONS

PRODUCT OPTIONS

Tournesol’s products are made-to-order. To easily add features to our planters, check our menu of standard options. Note that not all options are available for all products; we also have capabilities beyond the listed options. For something off-menu, speak to a Tournesol Advisor.

IRRIGATION SYSTEMS

Tournesol’s container irrigation systems are the best in the business, and one of the values of working with Tournesol. Learn more about the systems details below. Speak to a Tournesol Advisor for help selecting irrigation systems for your next project.

Tournesol Urban Rectangle & Square Planters

TOURNESEAL

Need it watertight? Specify TourneSeal, our waterproofing solution. This is highly recommended for planters that will not have drain holes. We apply specific coatings to our FRP, GFRC, and Steel products, if requested. Follow our warranty requirements and perform a field test for watertightness after installation, before filling with media.

Tournesol Urban Rectangle & Square Planters

MATCHING SAUCER

Capture runoff from drain holes to prevent surface staining. Available in GFRC and FRP with matching finishes. Speak to a Tournesol Advisor for help selecting saucers for your next project.

Tournesol Urban Rectangle & Square Planters
Tournesol Urban Rectangle & Square Planters

CUSTOM COLOR

Tournesol offers a broad range of standard colors for GFRC, FRP, and Powder-Coat, but we also offer custom colors depending on product and volume. Contact a Tournesol Advisor to discuss your custom color needs.

CASTERS

Recessed casters discreetly provide mobility and are available as an option for many of our planter collections. Planters receiving casters are built with reinforced raised bottoms, so that casters are hidden under skirted planter walls. Tournesol installs commercial-grade swiveling casters calculated to support the total weight of the filled planter. Adding casters adds .5” to height and reduces soil depth by 5”, please take this into consideration when selecting your planter height.

Tournesol Urban Rectangle & Square Planters

Casters are not offered for very large or very narrow planters where weight or tipping hazard can present a challenge. Unique caster configurations are available but outside of standard options. Speak to a Tournesol Advisor about specifying unique options for your project.

DRAIN HOLES

Whether installing planters on-structure or at grade, thoughtful attention to drainage will keep water and debris from collecting on non-permeable surfaces. We manufacture our GFRC and Steel planters standard with drain holes. For no additional cost, we can produce these planters without holes. Our FRP planters are manufactured without drain holes so they can be drilled as required in the field.

Tournesol Urban Rectangle & Square Planters

We can add drain holes to FRP planters using our standard drain hole configuration at no additional cost. See chart for details. Unique drainage configurations are available but outside of standard options. Speak to a Tournesol Advisor about specifying unique options for your project.

CARE & MAINTENANCE

CARE & MAINTENANCE (FRP FIBERGLASS)

The interior of our FRP planters is sealed with Asphalt Emulsion Henry 107, which acts as a water-resistant sealer and damp-proofer. Planters in exterior applications may have drain holes in the bottom; if not, a pump-out (or siphon) tube must be used to remove water. Water standing at the bottom of the pot over a long period will harm the plant(s) and may break down the planter sealant. A touch-up kit is sent with FRP planters, contact Tournesol for Touch-Up Application and Repair instructions, as needed. Our fiberglass planters are designed to hold up to the elements, yet they may still scratch, crack, or chip if care is not taken.

Clean Smooth (painted) finishes by gently scrubbing with soap and water applied with a soft brush or sponge; do not use abrasives on Smooth finishes.

-Clean Orange Peel and Rough Stucco (textured) finishes with soap and water applied by a gentle spray from a pressure washer. Do not scrub textured finishes with stiff brushes, steel wool, or other abrasives. -Do not push or pull full-planted pots by the top lip.

CARE & MAINTENANCE (GFRC LIGHTWEIGHT CONCRETE)

Concrete is a porous surface that absorbs moisture and minerals, which can cause changes to the surface’s appearance. Like most concrete surfaces, our GFRC can be sealed using commercially available clear concrete sealers, Tournesol uses Brightstone Sealer. Follow the manufacturer’s instructions when reapplying.

Planters in exterior applications have standard drain holes in the bottom. As an option, you may request a planter without a drain hole, yet you must use a pump-out (or siphon) tube to remove water. Water standing in the bottom over a long period will harm the plant(s); it may eventually break down the interior damp-proofing material and compromise the structural integrity of (crack or break) the planter if water remains in the bottom of the planter in climates where freezing occurs.

The interior of each planter is sealed with Xypex Concentrate as a water-resistant, damp-proofing layer to prevent most efflorescence (water and dissolved minerals transmitted from the pot’s interior to the outside surface). Small surface stress cracks may eventually appear in the container but are typically restricted to the face coat of the concrete, not the stronger backing coat, and will not affect the overall strength and integrity of the planter. A touch-up kit is sent out with GFRC planters, contact Tournesol for application and repair instructions as needed, per finish.

Though GFRC planters are designed to hold up to the elements, they can still scratch, crack, or chip if care is not taken.

- Do not scrub with abrasives.
- Do not push or pull full-planted pots by the top lip.
- Rinse products well to wash away soap and grease.
- Do not use harsh chemicals on the planters or in proximity.
- Clean GFRC finishes with soap & water applied by a bristle brush to get into the textured areas.

COLORS

GLASS FIBER REINFORCED CONCRETE - GFRC

We cast GFRC products in our plant in Juarez, Mexico. GFRC is glass fiber reinforced concrete and is made by combining a mixture of lightfast pigments, fine sand, cement, polymer, water, and alkali-resistant glass fibers. Our GFRC products are available in five textures and a palette of colors. The glass fibers used in GFRC help give this unique compound its strength.

Alkali-resistant fibers act as the principal tensile load-carrying member, while the polymer and concrete matrix bind the threads together and helps transfer loads from one fiber to another. Without fibers, GFRC would not possess its strength and would be more prone to breakage and cracking. GFRC products have the appearance of poured concrete but are lighter and stronger. Thin layers of materials are hand-applied to mold interiors with added strength from layers of fiberglass. Our production process is different for each of our GFRC textures. All GFRC products include binders to resist cracking and efflorescence.

OPTIONAL WATERPROOFING

TourneSeal, an optional waterproofing, can be applied to the planter interior. Once coated, we test for watertightness and recommend our customers do an additional test after installation before filling.

EXTERIOR SEALANT

Concrete is a porous surface that absorbs moisture and minerals, which can cause changes to the surface appearance. To preserve original appearance, our GFRC is sealed with clear concrete sealer.

INTERIOR SEALANT

Once cast, our planters have an interior sealant added as a water-resistant, damp-proofing layer to prevent most efflorescence and cracking.

COLORS (FIBERGLASS)

CHARCOAL (GFRC-LIGHTWEIGHT CONCRETE)

Tournesol Urban Rectangle & Square Planters

CLAY (GFRC-LIGHTWEIGHT CONCRETE)

Tournesol Urban Rectangle & Square Planters

SANDBOX (GFRC-LIGHTWEIGHT CONCRETE)

Tournesol Urban Rectangle & Square Planters

MIST (GFRC-LIGHTWEIGHT CONCRETE)

Tournesol Urban Rectangle & Square Planters

RAIN (GFRC-LIGHTWEIGHT CONCRETE)

Tournesol Urban Rectangle & Square Planters

MOSS (GFRC-LIGHTWEIGHT CONCRETE)

Tournesol Urban Rectangle & Square Planters

CELERY (GFRC-LIGHTWEIGHT CONCRETE)

Tournesol Urban Rectangle & Square Planters

SHARK (GFRC-LIGHTWEIGHT CONCRETE)

Tournesol Urban Rectangle & Square Planters

CAROB (GFRC-LIGHTWEIGHT CONCRETE)

Tournesol Urban Rectangle & Square Planters

SHADOW (GFRC-LIGHTWEIGHT CONCRETE)

Tournesol Urban Rectangle & Square Planters
